Coil-Over Shock Front 07-14 GM SUVs - SWB/LWB (GMT926/936/946)

Product image 1
Product image 2

Coil-Over Shock Front 07-14 GM SUVs - SWB/LWB (GMT926/936/946)

SK-2954

Coil Strut Assembly

This front coil-over strut SK-2954 is the perfect replacement for newer GMT900 GM SUVs equipped with electronic suspension. The Arnott designed custom-valved replacement strut fits the left or right side and is pre-assembled for safety with a new steel coil spring (Code 6DA, 7DA), upper shock mount, bump stop, spring seat and isolator. Arnott-designed struts are an excellent passive alternative for aging air or electronic suspension systems restoring comfort by replacing the OE shock with a completely new custom-valved coil over strut to provide a great ride.. Arnotts exclusive design includes a sensor which plugs into the electronic-damping system to eliminate dash panel error messages.

  • Converts active to passive
  • New Spring Seat, Isolator and Mounting Hardware
  • Installation Manual Available
  • Replace in Pairs
Active Or Passive Suspension: Passive
Adjustable: No
Adjustable Compression: No
Adjustable Damping: No
Adjustable Rebound: No
Adjustable Ride Height: No
Air Adjustable: No
Air Bladder: No
Air Bladder Material: No
Air Ride Suspension: No
Bearing Plate Included: No
Bladder Heavy Duty Crimping Rings Included: No
Bladder Sleeve(s) Included: No
Bladder(s) Included: No
Body Diameter: 50 (mm)
Body End Measuring Point: Center Eye
Boot Color: Black
Boot Included: Yes
Coil Over Springs Included: Yes
Coil Spring Included: Yes
Compressed Length: 361 (mm)
Dust Shield Included: Yes
Dust Shield Material: Rubber
Extended Length: 500 (mm)
Gas Charged: Yes
Grade Type: Standard
Heavy Duty Crimping Rings: No
Housing Material: Steel
Internal Construction Type: Twin-tube
Internal Damper Type: Hydraulic
Lower Mount Type: Cross Pin
Lower Mounting Isolator Included: Yes
Mounting Hardware Included: Yes
New Or Remanufactured: New
Outer Housing Diameter: 50 (mm)
Progressive Spring Rate: No
Protective Aluminum Can: No
Shock Absorber Rod End Measuring Point: Shoulder of Stud
Shock Spring Assisted: Yes
Shock/strut Color: Black
Spring Isolators Included: Yes
Spring Rate Type: Linear
Spring Seat Included: Yes
Springs Included: Yes
Travel Length: 139 (mm)
Upper Mount Type: Bolt
Upper Mounting Isolator Included: Yes
Make Model Year
Cadillac Escalade 2007-2014
Cadillac Escalade ESV 2008-2014
Chevrolet Suburban 1500 2007-2014
Chevrolet Tahoe 2007-2014
GMC Yukon 2007-2014
GMC Yukon XL 1500 2007-2014

Interchange is provided as a reference. Please check part specifications to verify fit.
Reference Number Reference Name
15815523 General Motors
15909490 General Motors
15911939 General Motors
15939373 General Motors
19300037 General Motors
19300039 General Motors
19300066 General Motors
19300066 General Motors
19353947 General Motors
19353949 General Motors
19353951 General Motors
19353951 General Motors
19368455 General Motors
19368457 General Motors
19420491 General Motors
19420493 General Motors
19420992 General Motors
20810263 General Motors
20810265 General Motors
20810267 General Motors
20810270 General Motors
22240300 General Motors
25821025 General Motors
25821028 General Motors
25845439 General Motors
25845441 General Motors
25845445 General Motors
25870256 General Motors
25888676 General Motors
25888678 General Motors
25888682 General Motors
25940740 General Motors
25940740 General Motors
$93.14

Original: $266.12

-65%
Coil-Over Shock Front 07-14 GM SUVs - SWB/LWB (GMT926/936/946)—

$266.12
