Air Strut Front Left 10-13 Porsche Panamera (970.1) - Incl. AWD AS-3411 Air Strut Front Left 13-18 Mercedes-Benz GL/GLS-Class (W166) - w/AIRMATIC, w/o ADS

AS-3346

New Air Suspension Strut

AS-3346 is a new, Arnott engineered, aftermarket air suspension strut from Eibach for the front left-hand side of the 2010-2013 Porsche Panamera (970.1 Chassis). This new assembly features a premium damper precisely tuned to ride and handle like the OE. The Arnott strut is built with Tier 1 components including a premium multi-ply cross-corded Continental ContiTech air sleeve protected by an aluminum can along with a dust cover and coupled to a CNC-machined top mount. This new air strut is designed and assembled in the USA with Arnotts long-lasting O-rings, polyurethane bump stop, heavy-duty crimping rings and a new 6 MM airline fitting.

  • Converts adaptive to passive
  • New custom tuned damper
  • Continental ContiTech air sleeve
  • Detailed installation manual available
  • Designed, assembled and tested in the USA
  • No core charge or handling
  • Replace in Pairs
Adjustable Compression: No
Air Adjustable: Yes
Air Ride Suspension: Yes
Bearing Plate Included: Yes
Bladder Heavy Duty Crimping Rings Included: Yes
Body End Measuring Point: Center Eye
Boot Color: Black
Boot Included: Yes
Coil Over Springs Included: N/A
Internal Damper Type: Hydraulic
Lower Mount Type: Clevis
Lower Mounting Isolator Included: No
Mounting Hardware Included: Yes
New Or Remanufactured: New
Progressive Spring Rate: Yes
Shock Absorber Rod End Measuring Point: Shoulder of Stud
Shock Spring Assisted: Yes
Spring Isolators Included: Yes
Spring Rate Type: Progressive
Spring Seat Included: No
Springs Included: N/A
Upper Mount Type: Stud
Upper Mounting Isolator Included: Yes
Make Model Year
Porsche Panamera 2010-2013

Interchange is provided as a reference. Please check part specifications to verify fit.
Reference Number Reference Name
97034305107 Porsche
97034305108 Porsche
97034305109 Porsche
97034305110 Porsche
97034305111 Porsche
97034305112 Porsche
97034305114 Porsche
97034305115 Porsche
97034305116 Porsche
97034305117 Porsche
97034305118 Porsche
97034305119 Porsche
97034305120 Porsche
97034305121 Porsche
97034305122 Porsche
97034305123 Porsche
$2,120.23
Air Strut Front Left 10-13 Porsche Panamera (970.1) - Incl. AWD AS-3411 Air Strut Front Left 13-18 Mercedes-Benz GL/GLS-Class (W166) - w/AIRMATIC, w/o ADS—
$2,120.23

Product Information

Shipping & Returns

Description

AS-3346

New Air Suspension Strut

AS-3346 is a new, Arnott engineered, aftermarket air suspension strut from Eibach for the front left-hand side of the 2010-2013 Porsche Panamera (970.1 Chassis). This new assembly features a premium damper precisely tuned to ride and handle like the OE. The Arnott strut is built with Tier 1 components including a premium multi-ply cross-corded Continental ContiTech air sleeve protected by an aluminum can along with a dust cover and coupled to a CNC-machined top mount. This new air strut is designed and assembled in the USA with Arnotts long-lasting O-rings, polyurethane bump stop, heavy-duty crimping rings and a new 6 MM airline fitting.

  • Converts adaptive to passive
  • New custom tuned damper
  • Continental ContiTech air sleeve
  • Detailed installation manual available
  • Designed, assembled and tested in the USA
  • No core charge or handling
  • Replace in Pairs
Adjustable Compression: No
Air Adjustable: Yes
Air Ride Suspension: Yes
Bearing Plate Included: Yes
Bladder Heavy Duty Crimping Rings Included: Yes
Body End Measuring Point: Center Eye
Boot Color: Black
Boot Included: Yes
Coil Over Springs Included: N/A
Internal Damper Type: Hydraulic
Lower Mount Type: Clevis
Lower Mounting Isolator Included: No
Mounting Hardware Included: Yes
New Or Remanufactured: New
Progressive Spring Rate: Yes
Shock Absorber Rod End Measuring Point: Shoulder of Stud
Shock Spring Assisted: Yes
Spring Isolators Included: Yes
Spring Rate Type: Progressive
Spring Seat Included: No
Springs Included: N/A
Upper Mount Type: Stud
Upper Mounting Isolator Included: Yes
Make Model Year
Porsche Panamera 2010-2013

Interchange is provided as a reference. Please check part specifications to verify fit.
Reference Number Reference Name
97034305107 Porsche
97034305108 Porsche
97034305109 Porsche
97034305110 Porsche
97034305111 Porsche
97034305112 Porsche
97034305114 Porsche
97034305115 Porsche
97034305116 Porsche
97034305117 Porsche
97034305118 Porsche
97034305119 Porsche
97034305120 Porsche
97034305121 Porsche
97034305122 Porsche
97034305123 Porsche
